EPIC® H-Q 8

Bodite prvi in ocenite ta izdelek

Naziv

Koda izdelka

Min. presek povezovalnega vodnika (mm2)

Maks. presek povezovalnega vodnika (mm2)

Min. delovna temperatura

Cena

Količina

H-Q 8 BCM (1)

44420526

0.5 mm2

4 mm2

-40 °C

15,92 €

Rok dobave sporočimo po obdelavi naročila.

H-Q 8 SCM (1)

44420527

0.5 mm2

4 mm2

-40 °C

15,95 €

Na zalogi, predviden rok dobave 5-8 delovnih dni.

EPIC® H-Q 008/0 FC

44423375

0.14 mm2

4 mm2

-40 °C

2,97 €

Min. količina za naročanje: 10

Na zalogi, predviden rok dobave 5-8 delovnih dni.

EPIC® H-Q 008/0 MC

44423374

0.14 mm2

4 mm2

-40 °C

2,97 €

Min. količina za naročanje: 10

Na zalogi, predviden rok dobave 5-8 delovnih dni.

Benefits

Can be connected to market-standard connectors.
High power up to 16 A despite extremely space-saving design for very small devices.
Crimp termination creates a vibration-proof connection, provides maximum contact protection between the contact and cable and is suitable for automated assembly.
Insert suitable for plastic and metal housings
Space-saving

Applications

For use with housings of the EPIC® H-Q series.
For connecting devices and machines to a power supply in various applications
Typical areas of application are electric motors and servo drives.
Servo applications - power drive systems
Mechanical engineering
Plant engineering

Notes

Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.
Photographs and graphics are not to scale and do not represent detailed images of the respective products.
